OpenMesh
|
|
OpenMesh
|
Public Member Functions | |
| SmartHalfedgeHandle (int _idx=-1, const PolyConnectivity *_mesh=nullptr) | |
| SmartHalfedgeHandle | next () const |
| Returns next halfedge handle. | |
| SmartHalfedgeHandle | prev () const |
| Returns previous halfedge handle. | |
| SmartHalfedgeHandle | opp () const |
| Returns opposite halfedge handle. | |
| SmartVertexHandle | to () const |
| Returns vertex pointed to by halfedge. | |
| SmartVertexHandle | from () const |
| Returns vertex at start of halfedge. | |
| SmartEdgeHandle | edge () const |
| Returns incident edge of halfedge. | |
| SmartFaceHandle | face () const |
| Returns incident face of halfedge. | |
| PolyConnectivity::ConstHalfedgeLoopRange | loop () const |
| Returns a range of halfedges in the face of the halfedge (or along the boundary) (PolyConnectivity::hl_range()) | |
| PolyConnectivity::ConstHalfedgeLoopCWRange | loop_cw () const |
| Returns a range of halfedges in the face of the halfedge (or along the boundary) (PolyConnectivity::hl_cw_range()) | |
| PolyConnectivity::ConstHalfedgeLoopCCWRange | loop_ccw () const |
| Returns a range of halfedges in the face of the halfedge (or along the boundary) (PolyConnectivity::hl_ccw_range()) | |
 Public Member Functions inherited from OpenMesh::SmartBaseHandle | |
| SmartBaseHandle (const PolyConnectivity *_mesh=nullptr) | |
| const PolyConnectivity * | mesh () const |
| Get the underlying mesh of this handle. | |
| Public Member Functions inherited from OpenMesh::HalfedgeHandle | |
| HalfedgeHandle (int _idx=-1) | |
| Public Member Functions inherited from OpenMesh::BaseHandle | |
| BaseHandle (int _idx=-1) | |
| int | idx () const |
| Get the underlying index of this handle. | |
| bool | is_valid () const |
| The handle is valid iff the index is not negative. | |
| void | reset () |
| reset handle to be invalid | |
| void | invalidate () |
| reset handle to be invalid | |
| bool | operator== (const BaseHandle &_rhs) const |
| bool | operator!= (const BaseHandle &_rhs) const |
| bool | operator< (const BaseHandle &_rhs) const |
| void | __increment () |
| void | __decrement () |
| void | __increment (int amount) |
| void | __decrement (int amount) |
| Public Member Functions inherited from OpenMesh::SmartHandleStatusPredicates< SmartHalfedgeHandle > | |
| bool | feature () const |
| Returns true iff the handle is marked as feature. | |
| bool | selected () const |
| Returns true iff the handle is marked as selected. | |
| bool | tagged () const |
| Returns true iff the handle is marked as tagged. | |
| bool | tagged2 () const |
| Returns true iff the handle is marked as tagged2. | |
| bool | locked () const |
| Returns true iff the handle is marked as locked. | |
| bool | hidden () const |
| Returns true iff the handle is marked as hidden. | |
| bool | deleted () const |
| Returns true iff the handle is marked as deleted. | |
| Public Member Functions inherited from OpenMesh::SmartHandleBoundaryPredicate< SmartHalfedgeHandle > | |
| bool | is_boundary () const |
| Returns true iff the handle is boundary. | |
